English 3/8" V Groove Bearing W2 RM2 Specification :
Bearing NO.: W2 RM2 RM2ZZ RM2RS
Type: V Groove Guide Bearing
Load Rating Dynamic C: 8,260 N
Load Rating Static Co: 2,650 N
Size :9.525*30.73*11.1mm
Dimensions (mm) | |||||
d | D | A | C | A1 | rs |
9.525 = 3/8" | 30.73 | 18.24 | 11.1 | 12.7 | 0.3 |
V Bearings RM2 Features :
The surface of outer ring is the "W" profile formed by the two "V" with an angle of 90 degrees. The internal or external side face can be matched separately with the concave or protrudable track that both have a "V' profile with the angle of 90 degrees, and also the internal side face can be matched well with the cylindrical track.
3/8" V Groove Bearing W2 RM2 Specification :
Bearing NO.: W2 RM2 RM2ZZ RM2RS
Type: V Groove Guide Bearing
Load Rating Dynamic C: 8,260 N
Load Rating Static Co: 2,650 N
Size :9.525*30.73*11.1mm
Dimensions (mm) | |||||
d | D | A | C | A1 | rs |
9.525 = 3/8" | 30.73 | 18.24 | 11.1 | 12.7 | 0.3 |
V Bearings RM2 Features :
The surface of outer ring is the "W" profile formed by the two "V" with an angle of 90 degrees. The internal or external side face can be matched separately with the concave or protrudable track that both have a "V' profile with the angle of 90 degrees, and also the internal side face can be matched well with the cylindrical track.
